Product Usage Scenarios
The Deutz F4L912 is widely used in various industrial and mobile applications, including construction equipment such as compactors, light excavators, and mobile lighting towers. It powers agricultural machinery including mid-sized tractors, irrigation pumps, and harvesting equipment. The engine is also commonly employed in material handling equipment like forklifts and terminal tractors, as well as in stationary applications such as generators and industrial pumps. Its air-cooled design makes it particularly valuable for operations in remote areas, extreme climates, and dusty environments where reliability and minimal maintenance are critical requirements.
Products Overview
Technical Parameter
Model | F4L912 | |||
No. of Cly | 4 | |||
Bore/stroke(mm) | 102/120 | |||
Displacement(L) | 3.77 | |||
Air-intake system | Naturally aspirated | |||
Power/Rev(kw/rpm) | 32/1500 | 380/1800 | ||
Max torque(N.m) | 270 | |||
Compression ratio | 20:1 | |||
Direction of rotation(facing cooling blower) | Clockwise | |||
Dimension(cm) | 107x82x102cm | |||
Weight(kg) | 425 |
Output power curve
Section plane of engine
