Product Usage Scenarios
The Deutz BF4L913 is widely used in construction equipment such as compact excavators, wheel loaders, and skid steer loaders. It powers agricultural machinery including mid-sized tractors, balers, and harvesters, as well as material handling equipment like forklifts and terminal tractors. The engine also serves as a dependable power source for stationary applications including generators, industrial pumps, and compressor systems. Its combination of compact dimensions, proven reliability, and Stage IIIA emissions compliance makes it suitable for urban construction projects, agricultural operations, and industrial applications where space constraints and environmental regulations are important considerations.
Products Overview
型号 Model | 缸径/行程 Bore/stroke (mm) | 排量 Displacement (L) | 功率/转速 power/ rotating speed (kw/rpm) | 尺寸 Dimension(cm) | 重量 Weight(kg) | |||
F2L912 | 100/120 | 1.88 | 14/1500 | 17/1800 | 20/2300 | 68*70*88cm | 260kg | |
F3L912 | 100/120 | 2.828 | 24/1500 | 29/1800 | 36/2300 | 38/2500 | 94*82*102cm | 375kg |
F4L912 | 100/120 | 3.77 | 32/1500 | 38/1800 | 46/2300 | 51/2500 | 107*82*102cm | 425kg |
F6L912 | 100/120 | 5.655 | 48/1500 | 60/1800 | 74/2300 | 78/2500 | 128*83*106cm | 550kg |
F4L912T | 100/120 | 3.77 | 41/1500 | 48/1800 | 52/2000 | 107*82*102cm | 450kg | |
F6L912T | 100/120 | 5.655 | 61/1500 | 72/1800 | 81/2300 | 85/2500 | 128*83*106cm | 580kg |
F6L913 | 102/125 | 6.128 | 51/1500 | 65/1800 | 79/2300 | 85/2500 | 128*83*108cm | 565kg |
BF4L913 | 102/125 | 4.086 | 47/1500 | 55/1800 | 66/2300 | 78/2500 | 107*83*108cm | 470kg |
BF6L913 | 102/125 | 6.128 | 74/1500 | 88/1800 | 112/2300 | 118/2500 | 141*85*113cm | 600kg |
BF6L913C | 102/125 | 6.128 | 84/1500 | 105/1800 | 125/2300 | 141/2500 | 141*85*120cm | 620kg |
F3L912W | 100/120 | 2.828 | 29/2150 | 31/2300 | 33/2500 | 118*85*106cm | 410kg | |
F4L912W | 100/120 | 3.77 | 39/2150 | 42/2300 | 44/2500 | 125*85*106cm | 450kg | |
F6L912W | 100/120 | 5.655 | 60/2150 | 63/2300 | 66/2500 | 160*85*106cm | 610kg |
Output power curve
Section plane of engine
