App lication range
Generator set
Compressor set
Construction machinery
Agriclltural machinery
Products Overview
Technical Parameter
| Model | F4L913 | |||
| No. of Cly | 4 | |||
| Bore/stroke(mm) | 102/125 | |||
| Displacement(L) | 4.086 | |||
| Air-intake system | Naturally aspirated | |||
| Power/Rev(kw/rpm) | 34/1500 | 40/1800 | 50/2300 | 56/2500 |
| Max torque(N.m) | 250 | |||
| Compression ratio | 17:1 | |||
| Direction of rotation(facing cooling blower) | Clockwise | |||
| Dimension(cm) | 107x83x105cm | |||
| Weight(kg) | 450 | |||
Output power curve
Section plane of engine
