Product Usage Scenarios
The Deutz BF6L913C is widely used in heavy-duty construction equipment such as excavators, wheel loaders, and bulldozers, as well as in agricultural machinery including large tractors and combine harvesters. It powers material handling equipment like port cranes and heavy forklifts, and serves as a reliable energy source for stationary applications including industrial generators and pump systems. The engine's combination of power density, durability, and proven technology makes it particularly suitable for construction projects, agricultural operations, and industrial applications where dependable performance and easy maintenance are essential requirements.
Products Overview
型号 Model | 缸径/行程 Bore/stroke (mm) | 排量 Displacement (L) | 功率/转速 power/ rotating speed (kw/rpm) | 尺寸 Dimension(cm) | 重量 Weight(kg) | |||
F2L912 | 100/120 | 1.88 | 14/1500 | 17/1800 | 20/2300 | 68*70*88cm | 260kg | |
F3L912 | 100/120 | 2.828 | 24/1500 | 29/1800 | 36/2300 | 38/2500 | 94*82*102cm | 375kg |
F4L912 | 100/120 | 3.77 | 32/1500 | 38/1800 | 46/2300 | 51/2500 | 107*82*102cm | 425kg |
F6L912 | 100/120 | 5.655 | 48/1500 | 60/1800 | 74/2300 | 78/2500 | 128*83*106cm | 550kg |
F4L912T | 100/120 | 3.77 | 41/1500 | 48/1800 | 52/2000 | 107*82*102cm | 450kg | |
F6L912T | 100/120 | 5.655 | 61/1500 | 72/1800 | 81/2300 | 85/2500 | 128*83*106cm | 580kg |
F6L913 | 102/125 | 6.128 | 51/1500 | 65/1800 | 79/2300 | 85/2500 | 128*83*108cm | 565kg |
BF4L913 | 102/125 | 4.086 | 47/1500 | 55/1800 | 66/2300 | 78/2500 | 107*83*108cm | 470kg |
BF6L913 | 102/125 | 6.128 | 74/1500 | 88/1800 | 112/2300 | 118/2500 | 141*85*113cm | 600kg |
BF6L913C | 102/125 | 6.128 | 84/1500 | 105/1800 | 125/2300 | 141/2500 | 141*85*120cm | 620kg |
F3L912W | 100/120 | 2.828 | 29/2150 | 31/2300 | 33/2500 | 118*85*106cm | 410kg | |
F4L912W | 100/120 | 3.77 | 39/2150 | 42/2300 | 44/2500 | 125*85*106cm | 450kg | |
F6L912W | 100/120 | 5.655 | 60/2150 | 63/2300 | 66/2500 | 160*85*106cm | 610kg |
Output power curve
Section plane of engine
