Product Usage Scenarios
The Deutz BF4L913 is widely used in construction equipment such as compact excavators, wheel loaders, and skid steer loaders, as well as in agricultural machinery including mid-sized tractors and harvesters. It also powers material handling equipment like forklifts and terminal tractors, and serves as a reliable energy source for stationary applications including generators and industrial pumps. The engine's combination of compact dimensions, modern emissions compliance, and proven reliability makes it particularly suitable for urban construction projects, agricultural operations, and industrial applications where space constraints and environmental regulations are important considerations.
Products Overview
| 型号 Model | 缸径/行程 Bore/stroke (mm) | 排量 Displacement (L) | 功率/转速 power/ rotating speed (kw/rpm) | 尺寸 Dimension(cm) | 重量 Weight(kg) | |||
| F2L912 | 100/120 | 1.88 | 14/1500 | 17/1800 | 20/2300 | 68*70*88cm | 260kg | |
| F3L912 | 100/120 | 2.828 | 24/1500 | 29/1800 | 36/2300 | 38/2500 | 94*82*102cm | 375kg |
| F4L912 | 100/120 | 3.77 | 32/1500 | 38/1800 | 46/2300 | 51/2500 | 107*82*102cm | 425kg |
| F6L912 | 100/120 | 5.655 | 48/1500 | 60/1800 | 74/2300 | 78/2500 | 128*83*106cm | 550kg |
| F4L912T | 100/120 | 3.77 | 41/1500 | 48/1800 | 52/2000 | 107*82*102cm | 450kg | |
| F6L912T | 100/120 | 5.655 | 61/1500 | 72/1800 | 81/2300 | 85/2500 | 128*83*106cm | 580kg |
| F6L913 | 102/125 | 6.128 | 51/1500 | 65/1800 | 79/2300 | 85/2500 | 128*83*108cm | 565kg |
| BF4L913 | 102/125 | 4.086 | 47/1500 | 55/1800 | 66/2300 | 78/2500 | 107*83*108cm | 470kg |
| BF6L913 | 102/125 | 6.128 | 74/1500 | 88/1800 | 112/2300 | 118/2500 | 141*85*113cm | 600kg |
| BF6L913C | 102/125 | 6.128 | 84/1500 | 105/1800 | 125/2300 | 141/2500 | 141*85*120cm | 620kg |
| F3L912W | 100/120 | 2.828 | 29/2150 | 31/2300 | 33/2500 | 118*85*106cm | 410kg | |
| F4L912W | 100/120 | 3.77 | 39/2150 | 42/2300 | 44/2500 | 125*85*106cm | 450kg | |
| F6L912W | 100/120 | 5.655 | 60/2150 | 63/2300 | 66/2500 | 160*85*106cm | 610kg | |
Output power curve

Section plane of engine
