Product Usage Scenarios
The Deutz F6L912 is ideally suited for a wide range of industrial, construction, and agricultural applications. It is commonly used to power medium-duty equipment such as construction machinery (e.g., excavators, loaders, and compressors), agricultural tractors and harvesters, forestry equipment, and stationary systems like generators and industrial pumps. Its air-cooled design makes it particularly valuable in remote, dusty, or extreme-temperature environments where reliability is critical.
Products Overview
Technical Parameter
| Model | F6L912 | |||
| No. of Cly | 6 | |||
| Bore/stroke(mm) | 100/120 | |||
| Displacement(L) | 5.63.77 | |||
| Air-intake system | Naturally aspirated | |||
| Power/Rev(kw/rpm) | 48/1500 | 60/1800 | 74/2300 | 78/2500 |
| Max torque(N.m) | 230 | |||
| Compression ratio | 17:1 | |||
| Direction of rotation(facing cooling blower) | Clockwise | |||
| Dimension(cm) | 128*83*106cm | |||
| Weight(kg) | 550 | |||
Output power curve

Section plane of engine
