The compact V6 design of the TCD2015V06 makes it particularly suitable for equipment where space constraints are critical while demanding substantial power. Its primary applications include large construction machinery such as 40-ton class excavators, high-capacity wheel loaders, and heavy-duty mobile cranes. Additionally, it serves as an ideal power source for agricultural equipment like high-horsepower harvesters and tractors, as well as specialized vehicles in mining, material handling, and industrial sectors where a combination of compact dimensions and high power output is essential for operational efficiency.
Products Overview
TCD2015 V06 | A | B | C | |
mm | 985 | 932 | 1141 | |
Cyl No. and Arrangement | 6-Cyl V-line | |||
Bore/Stroke(mm) | 132/145 | |||
Air-intake way | Turbo charged cooling | |||
Combustion system | Direct injection | |||
Cooling way | Water-cooled | |||
Displacement(L) | 11.9 | |||
Max.Torque(N.m) | 2080 | |||
Power(kw) | 240~360 | |||
Power(hp) | 322~483 | |||
Speed(rpm) | 1900/2100 | |||
Net Weight(kg) | 1020 | |||
Weight(kg) | 1150 | |||
Dimension(L*W*H/cm) | 140*120*140 | |||
HS code: | 8408909390 | |||
Application: | construction machinery / generator set / mining equiment / water pump / truck | |||
Certification | ISO9001:2000 | |||
Warranty | 12 Months / 1000 Hours | |||
Quality Control | The engines have been rigorously tested | |||
Payment | T/T, Western Union. | |||
Service | Guidance on product issues through online and video support | |||
The price varies based on configu-ration, serial number, and part quality. For an accurate quote, contact a supplier with your specific engine serial number ornameplate. | ||||
