We stock the DEUTZ BF6M1013FC as a stripped long block for customers who prefer to reuse their existing injection pump and manifolds. Key differentiators from the EC variant: an 8-bolt crankshaft flange instead of 10-bolt, and a thermostat housing rotated 15 degrees for skid steer clearance. Each engine is compression-tested at our Ningbo warehouse before dispatch. No reconditioned parts used — only new liners and piston rings sourced from Chinese ISO 9001 foundries.
Products Overview
BF6M1013FC | A | B | C | |||
mm | 1162 | 683 | 990 | |||
Cyl No. and Arrangement | 6-Cyl in-line | |||||
Bore/Stroke(mm) | 108/130 | |||||
Air-intake way | Turbo charged cooling | |||||
Combustion system | Direct injection | |||||
Cooling way | Water-cooled | |||||
Displacement(L) | 7.14 | |||||
Max.Torque(N.m) | 1050 | |||||
Power(kw) | 166 | 186 | 223 | |||
Power(hp) | 223 | 249 | 299 | |||
Speed(rpm) | 1500 | 1800 | 2300 | |||
Net Weight(kg) | 572 | |||||
Weight(kg) | 650 | |||||
Dimension(L*W*H/cm) | 156*84*123 | |||||
HS code: | 8408909390 | |||||
Application: | construction machinery / generator set / mining equiment / water pump / truck | |||||
Certification | ISO9001:2000 | |||||
Warranty | 12 Months / 1000 Hours | |||||
Quality Control | The engines have been rigorously tested | |||||
Payment | T/T, Western Union, Alibaba online payment. | |||||
Service | Guidance on product issues through online and video support | |||||
The price varies based on configu-ration, serial number, and part quality. For an accurate quote, contact a supplier with your specific engine serial number ornameplate. | ||||||
