The DEUTZ BF6M1015C is a 6-cylinder inline diesel engine with 12.0 liters displacement. Bore × stroke: 132mm × 145mm. Turbocharged with aftercooling. Mechanical in-line injection pump – no ECU, no common rail, no crank position sensor. Power: 280–300 kW at 1500–2100 rpm. Torque: 2000 N·m at 1800 rpm.Emissions: EU Stage II / EPA Tier 2. The C-version uses purely mechanical fuel control, making it immune to electrical faults, EMP, or poor grid grounding. Individual cylinder heads allow per-cylinder rebuilds in-frame.Typical applications: 50–80 ton crawler cranes, hydraulic excavators, stationary cone crushers, and 350–500 kVA gensets. Also found in drilling rigs and piling equipment.We supply complete BF6M1015C engines, mechanical injection pumps, injectors, and gasket kits. Hot-tested before shipping. Provide your equipment model for fitment check.
Products Overview
BF6M1015C | A | B | C | |||
mm | 841 | 932 | 1170 | |||
Cyl No. and Arrangement | 6-Cyl V-line | |||||
Bore/Stroke(mm) | 132/145 | |||||
Air-intake way | Turbo charged cooling | |||||
Combustion system | Direct injection | |||||
Cooling way | Water-cooled | |||||
Displacement(L) | 11.906 | |||||
Max.Torque(N.m) | 1978 | |||||
Power(kw) | 285 | 271 | 300 | |||
Power(hp) | 382 | 363 | 402 | |||
Speed(rpm) | 1500 | 1800 | 2100 | |||
Net Weight(kg) | 850 | |||||
Weight(kg) | 1110 | |||||
Dimension(L*W*H/cm) | 136*122*144 | |||||
HS code: | 8408909390 | |||||
Application: | construction machinery / generator set / mining equiment / water pump / truck | |||||
Certification | ISO9001:2000 | |||||
Warranty | 12 Months / 1000 Hours | |||||
Quality Control | The engines have been rigorously tested | |||||
Payment | T/T, Western Union. | |||||
Service | Guidance on product issues through online and video support | |||||
The price varies based on configu-ration, serial number, and part quality. For an accurate quote, contact a supplier with your specific engine serial number ornameplate. | ||||||
