Product Usage Scenarios
The Deutz F3L912 is widely used in compact industrial and mobile equipment applications. It is commonly found in construction machinery such as light compressors, welders, and small excavators, as well as in agricultural machinery including irrigation pumps and tractors. Additionally, it serves as a reliable power source for stationary equipment like generators and hydraulic power packs, especially in remote or arid environments where its air-cooled advantage is critical.
Products Overview
Technical Parameter
Model | F3L912 | |||
No. of Cly | 3 | |||
Bore/stroke(mm) | 100/120 | |||
Displacement(L) | 2.8 | |||
Air-intake system | Naturally aspirated | |||
Power/Rev(kw/rpm) | 24/1500 | 29/1800 | 36/2300 | 38/2500 |
Max torque(N.m) | 170 | |||
Compression ratio | 17:1 | |||
Direction of rotation(facing cooling blower) | Clockwise | |||
Dimension(cm) | 94*82*102cm | |||
Weight(kg) | 375 |
Output power curve
Section plane of engine
