Product Application Scenarios
The Deutz F4L914 is widely used in medium-duty applications across multiple industries. It powers construction equipment such as small excavators, vibratory rollers, and light towers; agricultural machinery including mid-size tractors, balers, and irrigation pumps; industrial applications including generator sets (50-80 kVA), air compressors, and material handling equipment; as well as municipal vehicles such as street sweepers and maintenance equipment. Its air-cooled reliability makes it particularly valuable for operations in remote areas and extreme environments - from desert regions with high ambient temperatures to cold climates - where conventional liquid-cooled engines might face operational challenges, ensuring dependable performance in infrastructure-limited locations worldwide.
Products Overview
Technical Parameter
Model | F4L914 | |||
No. of Cly | 4 | |||
Bore/stroke(mm) | 100/120 | |||
Displacement(L) | 4.3 | |||
Air-intake system | Naturally aspirated | |||
Power/Rev(kw/rpm) | 50/2300 | 56/2500 | ||
Max torque(N.m) | 270 | |||
Compression ratio | 20:1 | |||
Direction of rotation(facing cooling blower) | Clockwise | |||
Dimension(cm) | 107x82x102cm | |||
Weight(kg) | 425 |
Output power curve
Section plane of engine
